Inventec N800G3 - 16 Summary of Sensor

B800G3 BMC Specification
- 26 -
16.SUMMARY OF SENSOR
SI: Sensor Initialization SC: Sensor Capabilities
AM: Assertion Mask DM: Deassertion Mask RM: Reading Mask TM: Settable/Readable Threshold Mask
SENSOR # SENSOR NAME SENSOR TYPE EVENT/READING TYPE OFFSET
21h Outlet_Temp
Temperature (01h) Threshold (01h)
SI:7Fh
SC: 68h
AM: 0A80h
DM: 7A80h
TM: 3f3fh
26h CPU0_VR_Temp
29h PCH_Temp
27h CPU1_VR_Temp
22h
CPU 0 Tem p
24h
CPU 1 Tem p
0x20 Inlet_Temp Temperature (01h) Threshold (01h)
SI:7fh
SC: 68h
AM: 0A80h
DM: 7A80h
TM: 3f3fh
23h CPU0_Margin_Temp
Temperature (01h) Threshold (01h)
SI: 7fh
SC: 68h
AM: 0000h
DM: 0000h
TM: 0000h
25h
CPU1_Margin_Temp
A1h
CPU0 DIMMTEMP A0
A2h
CPU0 DIMMTEMP A1
A4h
CPU0 DIMMTEMP B0
A5h
CPU0 DIMMTEMP B1
A7h
CPU0 DIMMTEMP C0
A8h
CPU0 DIMMTEMP C1
AAh
CPU0 DIMMTEMP D0
ABh
CPU0 DIMMTEMP D1
B1h
CPU1 DIMMTEMP A0
B2h
CPU1 DIMMTEMP A1
B4h
CPU1 DIMMTEMP B0
B5h
CPU1 DIMMTEMP B1
B7h
CPU1 DIMMTEMP C0
B8h
CPU1 DIMMTEMP C1
BAh
CPU1 DIMMTEMP D0
BBh
CPU1 DIMMTEMP D1
0x1
FAN1_RPM
FAN (04h) Threshold(01)
SI:73h
SC: 68h
AM: 7a95h
DM: 7a95h
TM: 3f3fh
0x2
FAN2_RPM
0x3
FAN3_RPM
