Inventec N800G3 - Back View; Front View

Introduction
2015-MNU-000023
6
1.6.2 Front View
The system supports up to eight 2.5” HDDs or four 3.5” HDDs. The front view of this 1U server
allows easy access to HDDs. In addition, the front panel with buttons and system LEDs is
located on the front.
Figure 1-5 Front View – 8x2.5”HDDs
Figure 1-6 Front View – 4x3.5”HDDs
1
HDDs
2
HDD Status LED
3
HDD Activity LED
4 Front Panel
1.6.3 Back View
The server back view includes the connectors of the external system devices.
Figure 1-7 Back View
1
AC Power Connector 1
2
AC Power Connector 2
3
VGA Connector
4
10G NIC Port 4
5
10G NIC Port 3
6
Dual USB Port
