Hardware Operations
2015-MNU-000023
2-5
2.3.1 To remove the motherboard
Remove the nine screws that secure the motherboard.
Remove the motherboard out of the chassis along the direction of the arrow.
Figure 2-7 Removing the Motherboard
2.3.2 To install the motherboard
Reverse the steps above to install the motherboard.
2.4 Power Supplies
This server is designed with two 550W load balance and redundant power supplies platinum
version, or one 550 power supply platinum version
.
The location of power supplies on the server is shown below:
Figure 2-8 Power Supply Locations
