Inventec N800G3 - Power Distribution Board Connectors

Connectors
2015-MNU-000023
3-3
3.2 Power Distribution Board Connectors
Figure 3-3 Power Distribution Board
1 System Power Connector 5 P12VA Power Connector 2
2 P12VA Power Connector 1 6 PMBus Connector
3 System Power Connector 7 Power Supply Connector 2
4 Backplane Power Connector 8 Power Supply Connector 1
