Inventec N800G3 - 17 Threshold Settings and Converting Formulas

B800G3 BMC Specification
- 30 -
17. THRESHOLD SETTINGS AND CONVERTING FORMULAS
Sensor
Number
Sensor Name The Converting Formula
Upper
non-recoverable
Upper critical Upper
non-critical
Lower
non-critical
Lower critical Lower
non-recoverable
Voltage
1Ah STBY 3.3V
Actual_Reading (Volts) = Raw_Data x 0.02
0xb7 0xb4 0xb1 0x9c 0x94 0x8c
19h SYS_1.5V
Actual_Reading (Volts) = Raw_Data x 0.0098
0xa7 0xa4 0xa1 0x91 0x8e 0x8b
10h SYS_12V
Actual_Reading (Volts) = Raw_Data x 0.065
0xc8 0xc5 0xc2 0xb0 0xad 0xaa
12h SYS3.3V
Actual_Reading (Volts) = Raw_Data x 0.02
0xb7 0xb4 0xb1 0x9c 0x94 0x8c
11h SYS_5V
Actual_Reading (Volts) = Raw_Data x 0.028
0xd8 0xcd 0xc3 0xa9 0xa0 0x97
13h CPU0_VCORE
Actual_Reading (Volts) = Raw_Data x 0.0098
0xce 0xca 0xc6 0x97 0x93 0x8f
14h CPU1_VCORE
Actual_Reading (Volts) = Raw_Data x 0.0098
0xce 0xca 0xc6 0x97 0x93 0x8f
15h CPU0_ABDDR_VDD
Actual_Reading (Volts) = Raw_Data x0.0098
0x86 0x84 0x82 0x75 0x73 0x70
17h CPU0_CDDDR_VDD
Actual_Reading (Volts) = Raw_Data x0.0098
0x86 0x84 0x82 0x75 0x73 0x70
16h CPU1_ABDDR_VDD
Actual_Reading (Volts) = Raw_Data x0.0098
0x86 0x84 0x82 0x75 0x73 0x70
18h CPU1_CDDDR_VDD
Actual_Reading (Volts) = Raw_Data x0.0098
0x86 0x84 0x82 0x75 0x73 0x70
95h PSU1_Out_Vol
Actual_Reading (Volts) = Raw_Data x0.1
0 0x82 0 0 0x6e 0
96h PSU2_Out_Vol
Actual_Reading (Volts) = Raw_Data x0.1
0 0x82 0 0 0x6e 0
Temperature
21h Outlet_Temp
Actual_Reading (degrees C) = Raw_Data
0x3a 0x36 0x32 0x00 0x00 0x00
26h CPU0_VR_Temp Actual_Reading (degrees C) = Raw_Data
