6. LED CONTROL
There are UID LED x1 and System LED x1 which controlled by BMC as follows.
Name Color State Description
UID LED BLUE
OFF
Via Chassis Identify Command
Or
UID Button
BLINK Via Chassis Identify Command
ON
Via Chassis Identify Command
Or
UID Button
N800G3:
Name Power Status Critical Event LED State
System LED
OFF(S4/S5) NO
GREEN – OFF
AMBER – OFF
OFF(S4/S5) YES
GREEN – OFF
AMBER – BLINK
ON(S0/S1) NO
GREEN – ON
AMBER – OFF
ON(S0/S1) YES
GREEN – BLINK
AMBER – BLINK
K800G3:
Name Power Status Critical Event LED State
System LED
NO
GREEN – OFF
RED – OFF
YES GREEN – OFF
