Hardware Operations
2015-MNU-000023
2-9
2.6.1 To remove the system fans
Take the system fan out of the system fan cage.
Figure 2-14 Removing the System Fan
2.6.2 To install the system fans
Reverse the steps above to install the system fans.
2.7 PCI-E Expansion Cards and Riser Cards
This server is designed with two PCI-E riser cards to support the expansion cards.
The location of the PCI-E epxansion card assembly is shown below:
Figure 2-15 PCI-E Expansion Card Assembly Location
