1.3 Product Features
This chapter provides the detailed features for processor, chipset, system memory, onboard
storage, NIC, VGA, I/O and PCI slot with pictures for your reference.
Figure 1-1 Motherboard Overview
This motherboard supports Intel
®
Xeon™ E5-2600 V3 product family based on Intel
®
C610
Wellsburg platform chipset. The following highlights are the main features of the motherboard.
Table 1-2 Product Features
Processor
 2x Intel
®
Xeon
TM
E5-2600 V3 product family
 Designed up to 145W
 Dual Intel Sockets R3 (LGA2011-3)
Chipset
 Intel C610 Wellsburg
System Memory
 16x DDR4 2133MHz/s UDIMM/RDIMM/LRDIMMs
 4x DDR4 channel per CPU
 1.2V DDR4 standard I/O voltage
 Up to 8 ranks supported per channel, 1, 2, or 4 ranks
per DIMM
 Max memory capacity up to 256GB per processor
NIC
 Intel
®
NH I350/82599 OCP NIC
 I350 supports dual ports 1G Base-T connection
 82599 supports dual ports SFP+ connection
Server Management
 ASPEED AST2400, IPMI2.0 Complaint
