Connectors and Jumpers
2015-MNU-000009
Table 3-18 BIOS Recovery Jumper Function (J7)
3.14.2 ME Recovery Jumper (J8)
The location and function of ME Recovery Jumper on the motherboard is shown below:
Figure 3-15 ME Recovery Jumper
Table 3-19 ME Recovery Jumper Function (J8)
ME Recovery
3.14.3 Clear Password Jumper (J9)
The location and function of Clear Password Jumper on the motherboard is shown below:
