B800G3 BMC Specification
- 31 -
0x69 0x64 0x5c 0x00 0x00 0x00
29h PCH_Temp
Actual_Reading (degrees C) = Raw_Data
0x50 0x4b 0x46 0x00 0x00 0x00
27h CPU1_VR_Temp
Actual_Reading (degrees C) = Raw_Data
0x69 0x64 0x5c 0x00 0x00 0x00
22h
CPU 0 Tem p
Actual_Reading (degrees C) = Raw_Data
0x5f 0x5a 0x55 0x00 0x00 0x00
24h
CPU 1 Tem p
Actual_Reading (degrees C) = Raw_Data
0x5f 0x5a 0x55 0x00 0x00 0x00
0x20 Inlet_Temp
Actual_Reading (degrees C) = Raw_Data
0x32 0x2e 0x2a 0x00 0x00 0x00
2Ah DIMMG0_Temp
Actual_Reading (degrees C) = Raw_Data
0x4c 0x49 0x46 0x00 0x00 0x00
2Bh DIMMG1_Temp
Actual_Reading (degrees C) = Raw_Data
0x4c 0x4c 0x4c 0x00 0x00 0x00
FAN
01h FAN1_RPM
Actual_Reading (degrees C) = Raw_Data*80(K800G3)
0xff 0xff 0xff 0xe 0xd 0xc
02h FAN2_RPM
Actual_Reading (degrees C) = Raw_Data*80(K800G3)
0xff 0xff 0xff 0xe 0xd 0xc
03h FAN3_RPM
Actual_Reading (degrees C) = Raw_Data*80(K800G3)
0xff 0xff 0xff 0xe 0xd 0xc
04h FAN4_RPM
Actual_Reading (degrees C) = Raw_Data*80(K800G3)
0xff 0xff 0xff 0xe 0xd 0xc
For N800G3
01h FAN1_RPM
Actual_Reading (degrees C) = Raw_Data*160
0xff 0xff 0xff 0x7 0x6 0x5
02h FAN2_RPM
Actual_Reading (degrees C) = Raw_Data*160
0xff 0xff 0xff 0x7 0x6 0x5
03h FAN3_RPM
Actual_Reading (degrees C) = Raw_Data*160
0xff 0xff 0xff 0x7 0x6 0x5
04h FAN4_RPM
Actual_Reading (degrees C) = Raw_Data*160
0xff 0xff 0xff 0x7 0x6 0x5
05h FAN5_RPM
Actual_Reading (degrees C) = Raw_Data*160
0xff 0xff 0xff 0x7 0x6 0x5
