Figure 1-10 Back View LED
1 AC Power LED 1
2 AC Power LED 2
3 Speed LED of Management Port
4 Link/Activity LED of Management Port
5 UID LED
6 Link/Activity LED of 10G NIC Port
7 Speed LED of 10G NIC Port
The detailed LED information is shown below:
Table 1-5 LED Information
Front View LEDs
LED Type
Activity LED Status LED
Function
Green Green Red
2.5”/3.5”HDD
Tray LEDs
Off
Off
Off
Empty HDD slot
Idle:On
Access:Blinking
Off
Off
Online
On Off On Off line in the RAID mode
Idle:On
Access:Blinking
On Off Identify/Locate HDD
Blinking
On
On
Rebuilding
Blinking Off Off Hot spare
Off Off On Missing in the RAID mode
On
Off
On
Failed
LED Type
Color
Status
Function
Power LED
Green On DC power is power on.
- Off
No AC power or DC power is
power off.
ID LED Blue
On
(IPMI) the identification
command is enabled, or the ID
button on the front panel is
pressed.
Blinking
Unit selected for identification
via software.
