Introduction
2015-MNU-000009
1-5
9
Battery (BH1)
10
CPU1 DIMM Sockets（J61, J60, J59, J58）
11
Fan Connector 7 (J71)
12
Fan Connector 6 (J70)
13
Power Connector 3 (J62)
14 CPU1
15
CPU1 DIMM Sockets (J50, J51, J52, J53)
16 Fan Connector 5 (J69)
17
Fan Connector 4 (J68)
18
CPU0 DIMM Sockets (J57, J56, J55, J54)
19
Fan Connector 3 (J67)
20
Fan Connector 2 (J66)
21
CPU 0
22 Power Connector 2 (J63)
23
Fan Connector 1 (J65)
24
Fan Connector 0 (J64)
25
CPU0 DIMM Sockets (J49, J48, J47, J46)
26
CPU0 PE1A HD_MiniSAS Connector (J73)
27
CPU0 PE1B HD_MiniSAS Connector (J74)
28 SATA DOM Power Connector (J93)
29
SATA DOM Connector (J18)
30
HD_MiniSAS Connector 0/Onboard SATA Connector 2~5 (J13)
31
SATA Connector (J12)
32 Internal USB2.0 Connector (J45)
33
HD_MiniSAS Connector 1/Onboard SSATA Connector 0~3 (J32)
34 SSI Front Panel Connector (J28)
35
HD_MiniSAS SATA Connector (connected to ASM1061) (J36) (on
SKU 301 motherboard; not featured on SKU 302)
36
SGPIO Connector (J11)
37 CPU0 NIC OCP Slot (J21)
38
CPU0 PCIe Slot 6 (J81)
39 Intruder Jumper (J40)
40
Clear Password Jumper (J9)
41 QPI SLOW Mode Jumper (J26)
42
BIOS Recovery Jumper (J7)
43 Clear CMOS Jumper (J23)
44
CPU1 PCIe Slot 7 (J22)
