6700SR Refrigerated Sampler
122
Figure 38 Extended Programming: Quick View; Pacing and Distribution
PACING:
TIME, EVERY
__ HOURS, __ MINUTES
UNIFORM TIME PACED
FLOW PACED
EVENT PACED
NONUNIFORM TIME
NONUNIFORM TIME:
CLOCK TIMES
INTERVALS IN MINUTES
RANDOM INTERVALS
FLOW BETWEEN
SAMPLE EVENTS:
____ PULSES (1-9999)
PACED BY:
FLOW PULSES
FLOW MODULE VOLUME
QUANTITY AT INTERVAL
1. __ AT ___ MIN
2. __ AT ___ MIN
3. __ AT ___ MIN
FIRST SAMPLE AT
START TIME,
THEN ...
SAMPLE AT START?
YES NO
PROGRAM RUN TIME:
__ HOURS, __ MINUTES
TIME BETWEEN
SAMPLE EVENTS:
__ HOURS, __ MINUTES
TAKE SAMPLES AT:
1. START TIME
2. HH:MM
3. HH:MM
TAKE ___ SAMPLES
(1-999)
RUN CONTINUOUSLY?
YES NO
RUN CONTINUOUSLY?
YES NO
__ BOTTLES PER
SAMPLE EVENT (1-max)
SWITCH BOTTLES EVERY
___ SAMPLES (1-max)
SWITCH BOTTLES ON:
NUMBER OF SAMPLES
TIME
FIRST SWITCH TIME
AT __:__
SWITCH BOTTLES EVERY
__ HOURS, __ MINUTES
VOLUME
____ ml SAMPLES
DO YOU WANT
SAMPLE VOLUMES
DEPENDENT ON FLOW?
YES NO
FLOW PULSES
FLOW MODULE VOLUME
SAMPLE VOLUME:
___ ml (10-max)
SAMPLE VOLUME:
10 ML FOR EVERY
___ PULSES
DISTRIBUTION:
__ BOTTLES/SAMPLE
___ SAMPLES/BOTTLE
RUN CONTINUOUSLY
1 bottle
Ye s
Uniform Time Paced Only
No
No
Multi-bottle
Continued from
Figure 37
, Extended
Programming: Quick View; Equipment Set-
Up
, on page 121.
See
Figure 39
, Extended Programming: Quick
View; Programmed Sampler Enable
, on
page 123.
