ISCO 6700SR - Page 139

6700SR Refrigerated Sampler
121
Figure 37 Extended Programming: Quick View; Equipment Set-Up
__,____ ml BOTTLES
__ ft SUCTION LINE
AUTO SUCTION HEAD
_ RINSES, _RETRIES
NUMBER OF BOTTLES:
1 2 4 8 12 24
BOTTLE VOLUME IS
_____ ml (300-30000)
SUCTION LINE LENGTH
IS __ ft
(3-99)
AUTO SUCTION HEAD
ENTER HEAD
SUCTION HEAD OF
IS __ ft
(min-max)
_ RINSE CYCLES
(0-3)
RETRY UP TO _ TIMES
WHEN SAMPLING
(0-3)
ONE-PART PROGRAM
TWO-PART PROGRAM
__ BOTTLES AVAILABLE
ASSIGN BOTTLES
1 THRU __ TO
PART 'A' (1-max)
ONE PART PROGRAM
When Liquid Detector is on
See
Figure 38
, Extended Programming: Quick
View; Pacing and Distribution
, on page 122.
Continued from
Figure 31
, Quick View; Module
Setup
, on page 115.
