6700SR Refrigerated Sampler
120
Figure 36 Extended Programming: Quick View; Programming Screens
RUN "EXTENDED 1"
PROGRAM
VIEW REPORT
OTHER FUNCTIONS
"EXTENDED 1"
"EXTENDED 2"
"EXTENDED 3"
"EXTENDED 4"
SELECT NEW PROGRAM
CHANGE PROGRAM NAME
NAME: __________
ABCDEFGHIJKLMNOPQRST
UVWXYZ -&"0123456789
BACK-UP DONE
NAME: __________
ABCDEFGHIJKLMNOPQRST
UVWXYZ -&"0123456789
BACK-UP DONE
SAVE CHANGES?
YES NO
PROGRAM NAME:
"EXTENDED 1"
SITE DESCRIPTIONS:
"FACTORY "
SAVE CHANGES?
YES NO
5 MINUTE
DATA INTERVAL˜
UNITS SELECTED:
LENGTH: ft
see
Figure 31
, Quick View; Module Setup ,
on page 115.
See
Figure 38
, Extended Programming: Quick
View; Pacing and Distribution
, on page 122.
See
Figure 39
, Extended Programming: Quick
View; Programmed Sampler Enable
, on
page 123.
See
Figure 26
, Standard and Extended
Programming: Quick View; Start Times
, on
page 111.
See
Figure 37
, Extended Programming:
Quick View; Equipment Set-Up
, on page 121.
