ISHIDA Uni-3 Technical Manual

14 Uni-3 Technical Manual
Item
No.
Description Qty
1
Sheet (keysheet protect
Uni-3)
1
2
Edit-keysheet (
Uni-3)
1
3 Membrane keypad 1
4 PWB’PS-068’KEY 1
5Case 1
6 Platter (SUS304) 1
7Guard (Platter) 1
8 Cover customer 1
Cover customer
Bench Type L1 Only
1
9Lens 1
10 Support-power outlet
Bench Type L2 and Pole Type L2 Only
1
Support-power outlet
Bench Type L1 and Pole Type L1 Only
1
11 Support power outlet 1
12 Rubber plate support 4
13 Load cell (C2G1-25K-S18-25KG-350 NMB) 1
14 Base (load cell) 1
15 Harness ‘C3’ power 1
16 Power cord 1
17 Switch (BR-22C-11L-S) 1
18
Nameplate (
Uni-3 L2BENCH 30 lb USA)
1
Nameplate (
Uni-3 L1BENCH USA)
Nameplate (
Uni-3 L2 USA-M 30 lb)
Nameplate (
Uni-3 L1 30 lb USA)
19 Connector 1
20 PWB, PS-990G-2, MAIN 2M 1
21 PWB, PS-067, A/D 1
22 Cover (Base port) 1
23 Base 2 1
24 Bracket (Display-L1) 2
25 Display LCD dot (SMMD0202-A-00-SPC)
Bench Type L2 and Pole type L2 Only
2
LCD display module
(BTD2301E-TDWC-G-B-A02)
Bench Type L1 and Pole type L1 Only
26 Cover-printer front 1
27 Leg 4
28 Base 1 1
29 Power supply LSF10024 1
30 Cover-printer side 1
31 Printer nameplate (NL) (English) 1
32 Hinge (Plastic) 2
33
Display sheet (
Uni-3 L2B CUST-M30 lb USA)
Bench Type L2 and Pole Type L2 Only
1
Display sheet (
Uni-3 L1B CUST-M30 lb USA)
Bench Type L1 and Pole Type L1 Only
34
Display sheet (
Uni-3 L2B OP-M30 lb USA)
Bench Type L2 and Pole Type L2 Only
1
Display sheet (
Uni-3 L1B OP-M30 lb USA)
Bench Type L1 and Pole Type L1 Only
72 Spring coil 2 2
74 Bracket (for printer) 1
75 Bracket (magnet) 1
76 Label gnd cord 1
78 Bracket (cutter) 1
80 ZCAR1518-0730
Bench Type L2 and Pole Type L2 Only
1
ZCAT1518-0730
Bench Type L1 and Pole Type L1 Only
90 Harness C4 Power
Bench Type L2 Only
1
Harness S2 Power
Bench Type L1, and Pole Types L1 and L2
Only
91 Harness S2 display
Bench Type L2, Bench Type L1 and Pole Type
L1 Only
1
Harness S2 display L2
Pole Type L2 Only
92 Harness S2 keyboard 1
93 Harness S2 LCD
Bench Type L2
1
Harness C3 Display
Bench Type L1, Pole Type L2 and Pole Type L1
Only
94 Resistor Assy
Bench Type L2 and Pole Type L2 Only
1
Item
No.
Description Qty
Table 2-1. Uni-3 Scale Parts List
