ISHIDA Uni-3 - 1.4 LEVEL ADJUSTMENT

2 Uni-3 Technical Manual
1.2 Basic Information
Figure 1-1. Uni-3 Outer Dimensions for Bench Type
Figure 1-2. Outer Dimensions for Hanging Type
410 mm
16.1 in
370 mm
14.6 in
266 mm
10.5 in
159 mm
6.5 in
437 mm
17.2 in
420 mm
16.5 in
800 mm
31.5 in
678 mm
26.7 in
360 mm
14.2 in
146 mm
5.7 in
