Adjustment Mode 67
4.7 C07-Printer
Initializes and adjusts the thermal printer, including the Peel
Sensor, Label Gap Sensor and Thermal Head Density (darkness).
Parameter Display Description Choices
C07-01
Head
C07-01-01 Test Print Selects the printing test pattern. Press Print to
print out a test label.
0: CHECKER
1: NORMAL
C07-01-02 Head Type Displays the thermal head model. --
C07-01-03 Head Usage Displays the running distance of the thermal
head. When replacing the main board, enter the
running distance by using the numerical keypad.
Press Enter to overwrite. Enter 495344 and
press the Size key to unlock.
--
C07-01-04 Head Resistance Checks the resistance value of the thermal head.
Enter the resistance value by using the numerical
keypad. Press Enter to overwrite. Set as 1100.
This is the standard fixed value for
Uni-3
thermal heads.
--
C07-01-05 Backfeed 45 The adjustment value of the backward feeding.
Enter the adjustment value for 45mm. Press
Zero to store. Default: 1.0.
--
C07-01-06 Backfeed 60 The adjustment value of the backward feeding.
Enter the adjustment value for 60mm. Press Ta re
to store. Default: 1.0.
--
C07-01-07 Backfeed 80 The adjustment value of the backward feeding.
Enter the adjustment value for 80mm. Press
Feed to store. Default: 1.0.
--
C07-01-08 Thermal Head Temperature Selects whether to monitor and provide an error
if the thermal head over heats.
0: NO
1: YES
C07-01-09 Printer Initial Initializes the printer. Resets all printer settings to
default values. Press Zero followed by Enter to
execute.
--
C07-01-10 Head Initial Initializes the thermal head. Press Zero followed
by Enter to execute.
--
C07-01-11 Head Check Checks the thermal head print elements. Press
Zero to execute. A long beep indicates OK, an
error beep indicates one or more elements are
faulty.
--
C07-02
Peel Sensor
C07-02-01 Peel Sensor Level Monitors the output level of the peel sensor. Unblocked:
More than 130
Blocked:
Less than 20
C07-02-02 Peel Detect Adjusts the threshold value of the peel sensor. 0-255
C07-02-03 Peel Sensitivity Adjusts the sensitivity of the peel sensor. 0-255
C07-03
Label Type
C07-03-01 Label Type Selects the type of the thermal paper to be used. 0: RECEIPT
1: 130LA-1
3: 150LA-1
C07-03-02 Density Adjusts the print density (darkness). Default is 5. 0-9
C07-03-03 Print Direction Specifies the print direction. 0: STANDARD
1: INVERSE
C07-03-04 Label Shape Specifies shape of the label. 0: STANDARD
1: ROUNDING
C07-03-05 Label Gap Specifies the size of the gap between labels.
Default is 2.5 mm.
0.1mm -
99.9mm
C07-03-06 Round Label Specifies gap of round label. 0.1mm -
99.9mm
Table 4-5. C07 Printer Parameters
To Next Page
