86 Uni-3 Operation Manual
6.3 Specifications
Items Descriptions
Use Conditions Temperature: 23 to 104°F
-5 to 40°C
Humidity: 30 to 85%, non-condensing.
Power supply / power consumption AC100 – 120V / 1.0A
Weighing capacity scale interval 30 lb: 0 to 15/0.005 lb, 15 to 30/0.01 lb, 60 lb: 0.02 lb
15 kg: 0 to 6/0.002 kg, 6 to 15/0.005 kg, 30 kg: 0.01 kg
Weighting accuracy 1/3000
Operator/customer display L1: One line
16 segments x 23 digits, liquid crystal with backlight
L2: Two lines
<upper> 192 x 16 dots
<lower> 7 segments x 23 digits, liquid crystal with backlight
Printing method Direct thermal method
Thermal head 2.2 inch (56 mm) and 8 dots/mm
Printing speed 3.9 inch (100 mm) / second
Label size Label width: 38 mm to 64 mm
Label length: 30 mm to 175 mm
Number of label cassettes Non-cassette
Input/output LAN 1 channel
USB 1 channel
Drawer 1 channel
Program store medium Flash ROM (32M bytes)
Table 6-4. Specifications
