68 Uni-3 Technical Manual
4.8 C08-Calibration
Set the scale’s capacity and range and calibrate the weight readings.
4.8.1 Calibrate the Scale
1. Remove any objects from the platter and press the Zero key. Display reads: Span= 20000, Weight= 0.000.
2. Place full capacity weight on the scale, example 30 lb.
3. Press
Tare. Display reads: Span= 80000, Weight= 30.00.
C07-04
Label Feed
C07-04-01 Sensor Type Specifies if the Label Gap sensor is active. 0: NONE
1: LABEL
C07-04-03 Label Sensor Level & Sensitivity Enter a value to adjust the label sensor.
• Backing Paper Only: Approximately 150
• Backing Paper and Label: Approximately 50
0-255
C07-04-04 Label Gap Detect Adjusts the threshold value of the label gap
sensor. Any sensor readings below the set value
are ignored. This is useful when the label has
dark pre-printed areas that affect the sensor
output.
0-255
C07-04-05 Pre-Print Length Adjusts the length of the preprint section. Specify
the length in 0.1 millimeters. Default is 7.5 mm.
--
C07-04-06 Label Sensor Distance Specifies the distance between the label gap
sensor and the print elements on the thermal
head. Specify distance in 0.1 millimeters. Default
is 71.0 mm.
--
CO7-04-07 Back Feed Turns the backward feeding on or off. 1: NO
2: YES
C07-04-08 Peel Sensor Specifies if the peel sensor is active. 0: USE
1: NO USE
Display Description Choices
C08-01 Capacity Specifies the scale’s maximum capacity and units.
Changes to the capacity selection will not be saved until
calibration is performed.
Do not select 60 lb (or 30 kg) unless the scale is
equipped with a high capacity load cell.
0: 15 kg
1: 30 kg
2: 30 lb
3: 60 lb
9: 30 kg (1/6000)
C08-02 Range Specifies the accuracy of the scale.
Example: Single: 0-30 x 0.01 lb Multi: 0-15 x 0.005 lb, 15-30 x 0.01 lb
Changes to the range selection will not be saved until a
calibration is performed.
0: SINGLE
1: MULTI
C08-03 Area Setting Gravity setting. Used when the scale is calibrated in one location and used at
another. This step is password protected.
--
C08-04 Advanced Setting Enables steps C08-05 to C08-08. Used for factory verification. 1: OFF
2: ON
C08-09 Initialize Initializes calibration parameter. All settings are reset to default values after
initialization. To store settings again, perform the zero point adjustment and
the span adjustment. Press the span button to store the settings.
Use this function only when calibration is not operating
normally.
--
C08-10 Span Calibration See Section 4.8.1 below. --
Table 4-6. C08 Calibration
Parameter Display Description Choices
Table 4-5. C07 Printer Parameters (Continued)
CO8 CALIBRATION
&2&$/,%5$7,21
To Next Page
