ISHIDA Uni-3 Technical Manual

64 Uni-3 Technical Manual
4.0 Adjustment Mode
4.1 Enter Adjustment Mode
Enter 4000 and press Mode to enter the Adjustment mode menu. To exit the Adjustment mode, press Mode.
Many functions in the Adjustment mode are restricted to authorized service personnel. Enter the service
password 495344 and press PLU to access all Adjustment mode functions. All Adjustment mode functions are
available until the scale returns to normal operation mode.
Adjustment Mode Main Menu Screen
The Adjustment Mode for this device includes the following parameters:
*Full access requires the service password.
Use the
Up and Down arrow keys to select a parameter within the Adjustment menu. Press the Enter key to enter the
parameter. Use the
Up and Down arrow keys to move through the menu options. Use the Left and Right arrow keys
(or key in the corresponding number) to select the appropriate choice.
Example:
1. From the Adjustment mode main menu screen, press the
Down arrow several times to scroll to C11 OPTION CHECK.
2. Press
Enter to enter C11 OPTION CHECK.
3. Press
Enter to enter the parameter C11-01 SCANNER CHECK.
4. Use the
Down arrow key to scroll to C11-01-02 SCANNER
SELECT.
5. Press the
Right arrow key to view the available options
from
1: NONE to 3: UART
To change the current setting, enter the numeric value,
example 2, then press
Enter to select 2:USB.
6. Press
Mode to return to the main step C11 OPTION CHECK.
7. Exit the setup mode by pressing
Mode.
Note
< COO ADJUST >
&22$'-867`
1. Date Time
3. Display Check
4. Key Check*
5. Firmware Details
6. Memory Clear*
7. Printer*
8. Calibration*
10. Download*
11. Option Check*
13. Model*
C11 OPTION CHECK
&237,21&+(&.
< SCANNER CHK > [ENT]
&>6&$11(5&+.@
*SCANNER SEL 1:NONE
FVFDQQHUVHO
*SCANNER SEL 2:USB
FVFDQQHUVHO
