Item
No.
Description Qty
35 Motor stepping,49P048L0-00702 1
36 Bracket motor 1
37 Bracket 01 (Printer-rewind) 1
38 Axis-rewind 1
39 Bush (CSB-EPBF-0507-04) 1
40 OLTC6-1500B 1
41 Gear-rewind 1
42 3M-HTD-330 1
43 Gear dual 1
44 Gear driver 1
45 Cover (gear-driver) 1
46 Roller rubber 1
47 Frame (printer) 1
48 Level unit 07901 1
49 Holder guide label 1
50 Lever guide label 1
51 Holder label 1
52 Bracket (bobbin) 1
53 Spring (bobbin) 1
54 Shaft (bobbin) 1
55 Support (sensor) 1
56 Axle bush 32
57 Support (roll) 1
58 Cover 1
59 Bush, left 2
60 Axis01 1
61 Axis02 1
62 Shaft 1 1
63 Frame head 1
64 Bracket head 1
65 Thermal head CHX56-9719A 1
66 Bracket lock 1
67 Bracket push 1
68 Axis-hold (printer) 1
69 Tear bar 1
70 Bracket (sensor) 2
71 Spring coil 1 2
72 Spring coil 2 2
74 Bracket (for printer) 1
75 Bracket (magnet) 1
76 Label gnd cord 1
78 Bracket (cutter) 1
79 Screw 2
81 Bracket (peel sensor) 1
82 Peel Sensor 1
84 Bush 1
85 Shaft (POM) 1
86 Bracket of peel off 1
88 Label guide 1
89 Harness S2 Thermal Head 1
Item
No.
Description Qty
Table 2-2. Uni-3 Printer Parts
