22
DAILY 4x4 ‒ GUIDELINES FOR BODYBUILDERS
ELECTRONIC SUB-SYSTEMS
5.4 ELECTRICAL SYSTEM
– Printed 692.68.999 – 3 Ed. - Base 08-2020
 
243716
Figure 17
M3/MS3.Signal/power ground on fire guard M9.
 
Power ground on fire guard
 
243717
Figure 18
M4. Power, engine compartment ground near front right head-
light
