Iveco DAILY 4x4 2020 User Manual

DAILY 4x4 ‒ GUIDELINES FOR BODYBUILDERS
ELECTRONIC SUB-SYSTEMS
5.4 ELECTRICAL SYSTEM
23
– Printed 692.68.999 – 3 Ed. - Base 08-2020
243718
Figure 19
M5. Power, engine compartment ground near front left head-
light
M10. Power, engine compartment ground near front left head-
light
243719
Figure 20
M6. Power ground, in the cab, wall below dashboard
MS6. Signal ground, in the cab, wall below dashboard
M7. Power ground, in the cab, wall below dashboard
MS7. Signal ground, in the cab, wall below dashboard
