Chapter 4
MAINTENANCE
4.5
FAULT FINDING
4-24
Alarm name
(Japanese)
Alarm name
(English)
Class Description
ᖹ⾜⥺࣮࢝ࢯࣝ㡿ᇦእ P-CURS(Out) Status The floating position of the parallel cursor in the latitude/longitude
floating setting is out of the radius of PPI
Table 4.5-7 Error message list and alarm list for operations
Alarm name
(Japanese)
Alarm name
(English)
Class Description
᪉ࢹ࣮ࢱ↓ࡋ No Heading Data Status Cannot function because own ship heading is not available
y Operations for specifying TT acquisition/numerical display
y Changing to TM
y Changing to N Up/C Up
ࣉࣜࣄ࣮ࢺ୰࡛ࡍ On Preheating Status Transmission operation during preheating
᧯స㛫㝸ࡀ▷࠸࡛ࡍ Short Interval Status Transmission operation in the interval of 1 second or less between
standby and transmission
࢚࣮ࣛⓎ⏕୰࡛ࡍ Error Occurring Status Transmission operation during prohibition of transmission caused
by scanner error
᭱Ⅼᩘ࡛ࡍ Max Point Status Exceeded the maximum number of marks
ࣇࣝ↓ࡋ File Not Found Status File does not exists
እ㒊࣓ࣔࣜ↓ࡋ USB Memory Not Set Status USB memory does not exists
ࣇࣝㄞ㎸ࡳኻᩋ File Read Error Caution Failed to load the file
ࣇࣝ᭩ฟࡋኻᩋ File Write Error Caution Failed to write the file
✵ᐜ㔞㊊ Not Enough Space Status Insufficient capacity
ࣇ࢛࣮࣐ࢵࢺኻᩋ Format Error Caution Failed to format
ࣇࣝᩘ࣮࢜ࣂ࣮ Num of files Over Caution Writing data to the USB memory in which the number of the file
has reached to the maximum
ࣇࣝ๐㝖ኻᩋ File Erase Error Caution Failed to delete the file
デ᩿⤖ᯝ NG Self Test NG Caution Diagnosis NG
⮬⯪㧗⦋ᗘ࣮࢜ࣂ࣮ LAT(Out of Bounds) Caution The own ship's latitude is 80 degrees or more (indicating that some
functions are limited)
y Displays AIS, waypoint, mark/line, own ship trail, etc. for 80
degrees or more
y Input operations for 80 degrees or more (refer to "High
Latitude" alarm)
