2.3. Charging interfaces
The following charging interfaces can be selected for the JUICE ULTRA in various
combinations:
Charging interfaces
Charging interface
Max. Voltage capability [V]
Max. current capability [A]
CCS Combo 2 (not liquid
cooled cable)
1.000V DC
200A DC
CCS Combo 2 HPC (liquid
cooled cable)
1.000V DC
500A DC
CHAdeMO (not liquid
cooled cable)
500V DC
125A DC
CCS 1 US (not liquid cooled
cable)*
1.000V DC
200A DC
GB/T China (not liquid
cooled cable)*
750V DC
250A DC
22kW AC Socket Type 2
(with shutter)
400V 3~
32A AC
Table 2: Charging interfaces
Attention
The total performance of the double slot version is limited to a 250A grid
connection.
The total performance of the quadruple slot version is limited to a 500A
grid connection.
Hint
*The CCS 1 and GB/T options are special options for the automotive
industry.
