Juice ULTRA - Table 8: AC Input Switchgear Components for JUICE ULTRA Quadruple Slot Version

JUICE ULTRA - Operation Instructions and Installation Guide
Version 1-3A
Page 28 of 72
2 Product description
All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by alpitronic s.r.l.
Identifier
Description
-FB1
32A circuit breaker with fault current monitoring AC charging / 4P
-FB2
16A circuit breaker with fault current monitoring for auxiliary 230Vac / 4P
-QA1, -QA2,
-QA3, -QA4
125A circuit breaker / 3P / 16kA
-QB1
500A main switch / 4P
-TB1
Auxiliary 24V power supply
-XD1
Mains input busbars
-XF1
RJ45 ethernet network socket
Table 8: AC input switchgear components for JUICE ULTRA quadruple slot version
