4.1.4. JUICE ULTRA base positioning
Once the position of the JUICE ULTRA is defined on the installation site according to 4.1.3
the position of the JUICE ULTRA base and the cable entries from the foundation have to be
defined:
The JUICE ULTRA base is to be arranged eccentrically to the charging station. The outer
dimensions related to the center of the base plate are shown in Figure 24 for the double slot
version.
Figure 24: Distances between base plate and outer dimensions of charging station on the concrete
foundation double slot version (display/top view)
