3 Transport, storage, unpacking and handling
All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by alpitronic s.r.l.
11
12
13
Remove cover / remove the
water-cooling unit if mounted
*Remove screws on
the base plate of the
JUICE ULTRA
Close all doors, lift the
JUICE ULTRA with a
crane and remove the
pallet
Figure 20: Unpacking the JUICE ULTRA
The outer packaging is made of 100% recyclable wood, the inner packaging is made of
plastic and must be disposed separately.
*Attention
Before loosening the mounting screws between the JUICE ULTRA and
the pallet, the JUICE ULTRA must be protected against overturning.
This protection must be maintained until final mounting to the
foundation.
