8. Technical specifications
General technical data:
Parameter
Nominal value
Degree of protection
IP54
Mounting
Indoors and outdoors
Humidity transport or storage range
0 – 95% rel. (not fogging)
Humidity operational range
0 – 95% rel.
Pollution degree
pollution degree class 3
Storage temperature range
-40°C – +55°C
Operating temperature range
-30°C – +40°C (+55°C with derating)
Table 20: Technical data (general)
Type
Wide [mm]
Large [mm]
Height [mm]
Weight [kg]
double slot
version
854
420
2250
see Table 10 in
chapter 3.1
quadruple
slot version
854
732
2250
Table 21: Mechanical data
Electrical connection data depending on the configuration:
double slot version
Parameter
Nominal value
Operating voltage
400Vac +N +PE (±10%)
Frequency
50Hz (±5%)
Nominal current
max. 250A
Connection terminals cross section
connecting bolt 12mm
Rated peak withstand current I
pk
17kA (peak)
Rated short-time withstand current I
cw
4kA (rms)
Table 22: Electrical connection for double slot version
quadruple slot version
Parameter
Nominal value
Operating voltage
400Vac +N +PE (±10%)
Frequency
50Hz (±5%)
Nominal current
max. 500A
Connection terminals cross section
connecting bolt 2x12mm
Rated peak withstand current I
pk
17kA (peak)
Rated short-time withstand current I
cw
4kA (rms)
Table 23: Electrical connection for quadruple slot version
