JUICE ULTRA - Operation Instructions and Installation Guide
Version 1-3A
All rights reserved. The reproduction of this document, also partially, is allowed only with authorization by alpitronic s.r.l.
Attention
Installation and maintenance of the JUICE ULTRA ultra-fast charging
system for electric vehicles must only be carried out by qualified
personnel.
Before putting the system into operation, check the correct state of the
installation and all connections.
Electrostatic discharge
The control cabinet contains components and circuit boards that are
sensitive to electrostatic discharge. During assembly and maintenance,
sufficient ESD measures should be taken to protect the electronic
components (for example, wearing a grounding wristband).
Warning of hazardous electrical voltage
Installation and maintenance of the JUICE ULTRA must be carried out only
when power is removed. Before performing any installation, disassembly,
repair or replacement of components, switch off the external group switch
and the main switch in the JUICE ULTRA cabinet and do a voltage check
to make sure that the electrical power is disconnected from the system.
Inside the JUICE ULTRA cabinet, hazardous electrical voltages are
present (up to 1000Vdc) even if all circuit breakers are switched off, do not
allow unqualified persons to go near it.
Only JUICE ULTRA certified technicians are permitted to install,
disassembly, repair or replace components on the JUICE ULTRA. The
JUICE ULTRA cabinet doors has to be locked after installation, service or
repair operations.
Warning of hot surface
Some cabinet internal components of the JUICE ULTRA like power-stack
housings, cooling system, and conductors can remain hot long after the
power supply has been disconnected.
Prior to performing disassembly, repair or replacement of components
activities make sure that all components have cooled down.
Heavy weight
Please note that the individual components of the device can be very
heavy, for example the power-stacks.
Crushing
Please take care when assembling and disassembling components that
they do not squeeze a human body or body part.
