Juniper QFX5110 User Manual

Table 27: QSFP+ and QSFP28 Optical Module Receptacle Pinouts (continued)
SignalFiber
Rx3 (Receive)9
Rx2 (Receive)10
Rx1 (Receive)11
Rx0 (Receive)12
Table 28: QSFP+ MPO Fiber-Optic Crossover Cable Pinouts
PinPin
121
112
103
94
85
76
67
58
49
310
211
112
Related
Documentation
Determining Interface Support for the QFX3500 Device•
• Determining Interface Support for the QFX3600 Device
• Determining Interface Support for the QFX5100 Device
• Determining Transceiver Support for the QFX5110 on page 61
• Determining QFX5200 Optical Interface Support
• Determining QFX10000 Optical Transceiver and Cable Support
63Copyright © 2017, Juniper Networks, Inc.
Chapter 7: Transceiver and Cable Specifications

Juniper QFX5110 Specifications

General

Model	QFX5110
Power Supply	Dual, hot-swappable
Rack Units	1U
Operating Relative Humidity	5% to 90% non-condensing
Input Voltage	100-240 VAC
Operating System	Junos OS
Layer Support	Layer 2 and Layer 3
Virtual Chassis Support	Yes
Ports	48 x 10GbE SFP+
Jumbo Frames	9216 bytes
Operating Temperature	32°F to 104°F (0°C to 40°C)
Operating Altitude	Up to 3, 048 m
Management	CLI
AC Input Frequency	50/60 Hz
Storage Temperature	-40°C to 70°C
MTBF	Consult Juniper documentation for specific values.
