4—
USB Port
9—
Clock input and output connectors (10 MHz
and 1 PPS)
5—
Status LEDs
QFX5240 Network Port LEDs
The high-speed OSFP network ports on QFX5240-64OD and the high-speed QSFP-DD network ports
on the QFX5240-64QD use a single RGB LED to indicate link status, acvity on the link, or a fault
condion.
Figure 8: Network Port LEDs on a QFX5240-64OD Switch
1—
Network port LEDs
Figure 9: Network Port LEDs on a QFX5240-64QD Switch
1—
Network port LEDs
