QFX5240 Chassis Status LEDs
The QFX5240 has three LEDs that indicate system status. You can nd these LEDs to the le of the
network ports (see Figure 12 on page 23 and Figure 13 on page 23).
Figure 12: QFX5240-64OD Chassis Status LEDs
1—
SYS—System status
3—
RST—Reset buon
2—
ALM—Chassis alarm or fault
4—
ID-LED
Figure 13: QFX5240-64QD Chassis Status LEDs
1— SYS—System status 3—
RST—Rest buon
2—
ALM—Chassis alarm or fault
4—
ID-LED
