Settings:
● The drive shall stop at each position to allow processing of the workpiece, until the external control
gives the signal to continue, i.e., "start positioning". The external signal occurs via input I3. The drive
shall signal the control through an output that it has reached target with an accuracy of 10 increments,
so that the processing can begin.
● Let the position at which the workpiece starts have the value 0.
● Driving to this position (whether after "power on“, after error or as part of the positioning process) can
always occur at maximum speed = 1500 rpm.
● The rst stop shall be at position 100,000. The prole speed up to that point shall be 1000 rpm.
● The second stop shall be at position 200,000. The prole speed up to that position shall again be 1000
rpm.
● After that, the drive shall return to its starting position with maximally 1500 rpm.
Adjustments:
● PS.00:
PS.00: Posi / synchronous mode
Bit Meaning Value Explanation
0...2
Posi / synchro-
nous mode
5: Posi mode Activation of the positioning mode
4
Positioning /
target speed
0: PS.25 /
PS.25
The maximum prole speed is set via PS.25 "Index / speed".
All other bits can remain at the factory settings for this example and are explained in the following chapters.
● Block 0 denes the start position → PS.28 = 0
● Input I3 serves as "start positioning" → PS.29 = 64: I3 (X2A.12)
● block 0 → PS.23: Index / selection = 0
Position = 0 → PS.24: Index / position = 0
Permitted max. speed = 1500 rpm → PS.25 = 1500 rpm
next positioning step dened in block 1 → PS.26 = 1
no automatic starting of the drilling process, but waiting for "start position" command, i.e. "continuati-
on of the prole processing“ = 0: no and „position setting“ = 0: absolute
→ PS.27 = 0: no + absolute
● block 1 → PS.23: Index / selection = 1
Position = rst stopping point → PS.24: Index / position = 100.000
speed up to the rst stopping point → PS.25 = 1000 rpm
next positioning step dened in block 2 → PS.26 = 2
Stop at the position, i.e., "continuation of the prole proces-
sing" = 0:no / "position setpoint" = 0:absolute
→ PS.27 = 0: no + absolute
● block 2 → PS.23: Index / selection = 2
Posi- and synchronous operating
© KEB, 2012-10 COMBIVERT F5-A, -E, -H Page 7.12 - 45
7
