- 120 -
1.
Spark
plug
2.
Mounting
bolts
of
cy
linder
cover
3.
Cy
linder
cover
4.Cylinder
gasket
5. Cyl
inder
Note: In order
to guarantee
the seal betwee
n cylinder
cover and cy
linder block,
the cyli
nder cover would
withstand v
ery big
pre-ti
ghtening force of bolt.
Pre-tighteni
ng force value:
50Nm
曲轴箱
化油器
2
1
3
4
5
120
122
