3.3.5 Installation
Install wires of the starting motor; make sure the soldering
cup is properly installed.
Check whether the O-ring is damage, and replaced it with a
new one when necessary.
Cover the O-ring with engine oil, and install it onto the
starting motor.
Install the wire clip of the rear brake.
3.4 Starting Relay
3.4.1 Actuation Inspection
Remove the fender of the body.
Ensure there is a ―click‖ when turning on the starting motor
with the main switch remaining ―on‖.
If there is sound, it is ok.
If not：• check the voltage of the starting relay.
• check the ground loop of the starting relay.
• Actuate inspection on the starting relay.
3.4.2 Voltage Inspection of Starting Relay
Set up the main stand, measure the voltage between
the negative pole of the green/yellow wire in the
adaptor of the starting motor and the ground strap
connection of the body.
Hold on the brake tension rod with the main switch
emaining ―on‖, the voltage of the storage battery
must be in accordance with specification.
Continuity check and inspection of the wires when
the voltage between the ends of the starting motor is zero.
3.4.3 Inspection of Ground Loop of Starting Relay
Remove the adaptor of the starting relay.
Conduction inspection between the grey wire at the end
of conductor joint and the ground strap connection of
the body.
When pressing on the starting button, the conduction
Between the grey wire and the ground strap connection
of the body must be fine.
Inspection of the conduction of the starting button and wires when there is no conduction.
