4.3.2 Installation
Install the bulb in the opposite order of removal.
4.4 Front Turn Signal Lamp Bulb
Replacement
4.4.1 Unloading
Remove the pedal components.
Remove the front shield and disconnect the wire of headlight bulb.
Loosen set screws of turn signal lamp (3).
Take off the bulb socket.
4.4.2 Installation
Install the bulb in the opposite order of removal.
4.5 Taillight Bulb Replacement
4.5.1 Unloading
Take off the seat.
Remove the set screws so as to take off the lamp covers.
Disconnect the wire of taillight.
Take off the left and right backplates and taillight covers.
Take off the taillight.
4.5.2 Installation
Install the bulb in the opposite order of removal.
4.5.3 Taillight Bulb Replacement
4.5.3.1 Unloading
Remove set screws on the taillight covers.
Take off the taillight covers so as to remove the bulbs.
Take off bulbs from the sockets.
