4. Bulbs/Switches/Meters
Material Preparation--------------4.1 Meters----------------------4.6
Failure Diagnosis--------------4.2 Main Switches------------4.7
Headlight Bulb Replacement--------4.3 Speaker--------------------4.8
Front Turn Signal Lamp Bulb Replacement------4.4 Combined Switch--------4.9
Taillight Bulb Replacement -------4.5
4.1 Material Preparation
Notice of Work
Conduct examination of the switch (The switch could be removed from the motorcar before being examined).
4.2 Failure Diagnosis
The main switch is not "ON".
• The bulb is broken.
• The switch is broken.
• Poor contact at the adaptor or wire break.
4.3 Headlight Bulb Replacement
4.3.1 Unloading
Remove the pedal components.
Remove the front shield.
Disconnect the wire of headlight bulb.
Remove the set screws so as to remove the headlamp.
Take off the headlamp.
Take off the glass lens of the headlamp.
Keep the headlight in place; rotate the outlet
clockwise to remove the bulb.
To Next Page
