Check the wear of clutch sleeve.
Measure the outside diameter of clutch sleeve.
Allowable limit: 118.5mm。
Check the wear of clutch friction lining.
Measure the thickness of friction lining.
Allowable limit: 1.5mm。
14.6 Disassembly of clutch and driven wheel
Clutch spring compressor should be used for disassembling
clutch-pressing spring
Attentions:
Clutch spring compressor should be used for disassembling to
avoid any damage to the spring.
Fix the spring compressor and to remove the clutch fixing nut.
Relax the compressor and disassemble the clutch and driven
wheel
扳手：Wrench
离合器弹簧压缩器：Clutch spring compressor
Remove the spring sheath.
弹簧护套：Spring sheath
