Motorcycle Identification
1．The motorcycle indentification number is printed on the
frame ① , please see Figure 1-1. Indentification number:
LBB11B05?????????. The ninth number of the vehicle
indentification number is the chek code, the tenth one year code
and the eleventh one assembly factory code. The frame
nameplate is riveted on the left side ② of the frame.
Figure 1-1
2．The engine series number ① is printed on the outer shell
of crankcase, please see Figure 1-2.
Figure 1-2
Important Notices:
1．Please use the pure components manufactured by Qiangjiang. Use the components not complying with the
design specifications of Qiangjiang Company may cause damage to the engine.
2．Use only the metric instruments to do the maintainence operation. The metric bolt, nut and screw are not
interchangeable with the British fastener.
3．When reassembling, new washer, O ring, split pin and locking plate should be replaced.
4．When tightening bolt or nut, unless otherwise specified, bolt with larger diameter or near the inner side should
be tightened first, then along the diagonal line, gradually tighten the bolt to stated torque.
5．Wash the disassembled parts with cleaning solution. Lubricate all the sliding surfaces before assembling.
6．After assembling, please check all the components are assembled and operated in a proper way.
7. Eliminate the pollution and oil before measuring, and add the recommended lubricant onto the oil site when
assembling.
8. If the engine and drive system need to be stored for a long time after disassembling, please spread lubricant
onto the surface of the parts to prevent rusting and dust.
