7. Front wheel/front suspension
Preparation data-------------------------7.1
Fault diagnosis-------------------------7.2
Front wheel-------------------------7.3
Manipulation-------------------------7.4
Front fork assembly-------------------------7.5
7.1 Preparation data
Operation precaution
Before removing the front wheel, support the bottom body with jack etc to make the front wheel float on the
ground (Note: do not make the front wheel reverse).
When operating ,do not make the brake shoe block，friction plate component, front brake disc stained with grease.
Vehicle standard
Torque value Tools
Tap welding component fixing bolt 40-60 N·m Bearing removing pole
Front axle locking nut 55-62 N·m Locking nut wrench
Front muffler fixing bolt 37-44 N·m
7.2 Fault diagnosis
7.2.1 Turning hardness of direction handle
