The direction handle bearing has failed.
The direction handle bearing has been damaged.
The tire pressure is too low.
The tire leaks.
7.2.2 Direction unstable
The direction handle bearing has been damaged.
The tire pressure is not sufficient.
The front fork bends and the front axle bends.
The front wire deforms or skews.
7.2.3 Front wheel swing
The tire deforms.
The front axle bearing looses.
The tire is not good.
7.2.4 Turning hardness of rotor
The axle bearing has failed or the gear has failed.
7.2.5 Abnormal sound of front muffler
The muffler makes friction sound.
Each part bolt of the muffler loose.
7.3 Front wheel
7.3.1 Removing
Note:
The motorcycle must be supported firmly.
Loosen the brake cylinder component installation bolt.
Remove the brake cylinder component.
Put an appropriate bearing under the engine to raise the front wheel.
Loosen the front axle fixing nut（1）.
Remove the front axel（11）and front wheel.
Remove the gear seat component（2）.
Remove the front brake disc.
Remove the sleeve, oil sealing, bearing 6201-2RS, intermediate sleeve component, bearing 6201-2RS.
* Note: referring to the assembly and disassembly view of the QJ50T-21T front wheel on page 86.
7.3.2 Check
