- 72 -
Bulbs/Switches/Meters
1
Front
signal
lamp
2
Meter
3
Front
left
turn
signal
lamp
4
Front
right
turn
signal
lamp
5
Rear
left
turn signal l
amp
6 T
ailli
ght
7 Left rearvi
ew mirror
8 Right rear
view mirr
or
A
Certificate No. of front lamp:
E4 0014908
B
Certificate No. of front position lamp:
E4 50R-001765
C
Certificate No. of rear lam
p:
E4 50R-0014909
D
Certificate No. of front turn light:
E4 50R-001765
E
Certificate No. of rear turn light:
E9 50R-001493
F
Certificate No. of rear license lamp:
E3 001002
72
