Broken or damaged clutch friction lining wear of ball
Broken clutch-pressing spring polluted driving pulley surface
14.3 Left crankcase cover
Disassembly
Remove the fixing bolt of cover, and to remove the gasket
and fixed pin.
Attentions:
Cross disassemble the fixed bolts.
Remove the pilot pin.
14.4 Driving plate
14.4.1 Disassembly
Remove the fixing bolt of driving plate and to remove the left
half driving plate.
Remove the V-shaped belt from driving plate.
Check whether the v-shaped belt is cracking, whether the
rubber and cotton is falling off or abnormally worn
Measure the width of v-shaped belt.
