Preparing standards
Item
Specifications
Battery
Capacity/Type
12V-4AH/dry cell
Voltage
（20℃）
Full charge
13.1V
Obligatory
charge
12.3V(not working for 1h)
Charging current
standard：0.4A，rapid：4A
Charging time
standard：10-15h，rapid：30min
Magnetor
capacity
90W/8000rpm
Lighting coil impedance（20℃）
Green/Red - Black 2.0-2.5Ω
Charging coil impedance(20℃)
White – Black 1.5-2Ω
Voltage
adjuster
Type
Single-phase semi-wave charge under short circuit
Voltage limit
Lighting
Limit
14.0V±0.4V/5000rpm
13.5V/5000rpm
Charging
limit
14.8V±0.4V/5000rpm
Tightening torque force value Tool
Rectifier bolt 5.0 N·m Multiple fixing spanner
High tension coil fixing bolt 9.0 N·m Flywheel remover
Flywheel Fixing bolt 5.0 N·m Testing instrument
Body Shield Bolt 9.0 N·m Multimeter
1.2 Failure diagnosis
Power supply dead interrupted electric current
Battery overcharge Poor contact of the charging wire
Battery wire isn’t connected Poor contact of the charging system
Fuse blow Poor contact or short circuit of lighting system
Bad power switch
Low voltage Bad charging system
Bad battery charging Poor contact of the wire, short or open circuit
Poor contact Bad voltage current adjustor
Bad charging system Bad magnetor
