KEEWAY F-ACT EVO - Brake System Maintenance; 5. Brake; 5.2 Fault diagnosis

80
5. Brake
Maintenance instructions ----------------------5.1
Fault diagnosis ------------------------5.2
Front hydraulic brake--------------------------5.3
Rear hub brake-------------------------5.4
5.1 Maintenance instructions
Operation precautions
*Note:
*Check the brake before driving *
5.1.1Specifications
Item
Standard value (mm)
Available limit (mm)
Front disc thickness
4
3
Front friction plate thickness
5.0
4.0
Front brake disc diameter
190
-
Inside diameter of rear brake
hub
110
-
Rear brake shoe block
thickness
4.5
3.5
5.1.2 Torque value
pump body component fixing bolt 5-9 N·m Front cylinder component installation bolt
22-29 N·m
Hydraulic brake handle fixing bolt 5-9 N·m Rear fixing nut 100-113 N·m
5.2 Fault diagnosis
Brake
Poor braking performance
• When installing and removing, the brake components can not be stained with grease.
• The brake should be cleaned with specified cleaning agent in order to avoid the degradation of the brake
performance.
