7.3.3 Bearing change
Remove the front axle, front wheel and the left sleeve of the front wheel, intermediate sleeve component of the
front wheel.
Remove the oil sealing and bearing with the oil sealing puller and bearing puller.
Note: the removed bearing should be replaced with a new bearing.
When installing, smear the bearing with lubricating oil, then press in the bearing with bearing installation tools.
* Note:
• The bear must be pressed in parallel.
7.3.4 Installation
Conduct in accordance with the steps contrary to the
―removing‖
Take care to the following items:
Lubricate the front axle, gear seat component, oil sealing
(opening), sleeve, bearing 6201-2RS, intermediate sleeve
component.
The recommended lubricating oil is calcium-based
lubricating oil.
Install the front axle (11), front wheel, gear seat component (2), nut (1).
When installing the gear seat component (2), take care to combine the odometer gear seat well. If the front axle
has not been locked in combination, the odometer gear seat will deform.
Install the brake cylinder component onto the front
hub.
Tighten the front axle (as shown in the right
figure)
* Note: referring to the assembly and
disassembly view of the QJ50T-21T front
wheel on page 86.
Torque value
