Keithley SourceMeter 2420 User Manual

2400 Series SourceMeter
®
User’s Manual SCPI Command Reference 18-11
[:SENSe[1]]
:CURRent[:DC] Path to configure current: ✓
:RANGe Configure measurement range: ✓
[:UPPer]
<n>|UP|DOWN
Select range by specifying the expected
current reading.
1
1.05e-4 ✓✓
4
[:UPPer]? Query range. ✓
:AUTO <b> Enable or disable auto range.
2
ON ✓✓
4
:AUTO? Query auto range. ✓
:ULIMit? Returns I compliance range. ✓
:LLIMit <n> Set auto ranging lower limit (-105e-6
to 105e-6).
1e-6 ✓
:LLIMit? Query auto ranging lower limit. ✓
:NPLCycles <n> Specify integration rate (in line cycles):
0.01 to 10.
3
1.0 ✓✓
4
:NPLCycles? Query integration rate. ✓
:PROTection Path to configure current compliance: ✓
[:LEVel] <n> Specify current limit for V-Source.
1
1.05e-4 ✓✓
4
[:LEVel]? Query current compliance limit. ✓
:TRIPped? In current compliance: 1 (yes), 0 (no). ✓
:RSYNchronize <b> Enable or disable measure and
compliance range synchronization.
OFF
:RSYNchronize? Query range synchronization.
:VOLTage[:DC] Path to configure volts: ✓
:RANGe Configure measurement range: ✓
[:UPPer]
<n>|UP|DOWN
Select range by specifying the expected
voltage reading.
1
21 ✓✓
5
[:UPPer]? Query range. ✓
:AUTO <b> Enable or disable auto range.
2
ON ✓✓
5
:AUTO? Query auto range. ✓
:ULIMit? Returns V compliance range. ✓
:LLIMit <n> Set auto range lower limit.
1
0.21 ✓
:LLIMit? Query auto range lower limit. ✓
:NPLCycles <n> Specify integration rate (in line cycles):
0.01 to 10.
3
1.0 ✓✓
5
:NPLCycles? Query integration rate. ✓
:PROTection Path to configure voltage compliance: ✓
[:LEVel] <n> Specify voltage limit for I-Source.
1
21 ✓✓
5
1. The parameter values for this command are provided with the detailed command reference information. Detailed information on SCPI commands fol-
lows the last command summary table in this section.
2. For the Model 2430 Pulse Mode, auto range is invalid (error +831).
3. For the Model 2430 Pulse Mode, <n> = 0.004 to 0.100.
4. If source V is active.
5. If source I is active and auto ohms is disabled.
Table 18-6 (continued)
SENSe command summary
Command Description
Default
parameter SCPI
Source
memory
