2400 Series SourceMeter
®
User’s Manual Contact Check Function F-11
Auto clear off, immediate binning
Bin control at end of each point is sweep: :CALC2:CLIM:BCON IMM
The output will remain on between each sweep point if no contact check failure occurs. If
a contact check failure occurs before the execution of a sweep point, the output will be
turned off for that point. The test sequence will progress and perform a contact check on
the next point in the sweep. The output will not be turned on until a good contact is
detected.
Front panel contact check operation
Menu selections
Table F-2 summarizes the menu selections for various contact check modes. Note that
only those selections specific to contact check operation are shown here. See Section 1 for
complete menu listings, and Section 11 and Section 12 for details on triggering and limit
testing, respectively.
Table F-2
Contact check menu selections
Menu item* Description
CONFIG LIMIT Configure limit tests.
CONFIGURE LIMITS MENU
DIGOUT Set Digital I/O modes.
SIZE Select 3-BIT or 4-BIT fail pattern size.
MODE Select GRADING or SORTING mode.
H/W LIMITS Control and set mode for Limit 1 and Limit 4 tests.
LIMIT1(CMPL) Select Limit 1 (compliance) test.
LIMIT4(CCHK) Select Limit 4 (contact check) test.
CONTROL Enable/disable Limit 4 test.
DISABLE Disable contact check limit test.
ENABLE Enable contact check limit test.
DIGIO PATTERN Set contact check Digital I/O pattern (0-7, 3-bit;
0-15, 4-bit).
